Overview
The ZF 0501.214.010 OUTER CLUTCH DISK is a critical friction component engineered for the WG158 and WG200 series transmissions. This OEM genuine part sits within the multi-plate clutch pack assembly, where it transmits torque between rotating elements under hydraulic pressure. The SKU 0501.214.010 specifically functions as the outermost steel reaction plate, providing a durable surface against which the friction discs engage during gear shifts. Without this hardened disk, the clutch pack cannot maintain proper clamping force, leading to power loss during acceleration. It works in conjunction with the TRANSMISSION HOUSING to contain hydraulic fluid pressure, and its precise fit ensures minimal axial play within the drum assembly.
Symptoms of Failure
- Delayed or harsh gear engagement – When the outer clutch disk wears thin, hydraulic pistons must travel farther, causing noticeable lag when shifting from Neutral to Drive or Reverse.
- Torque converter shudder at highway speeds – A warped or glazed 0501.214.010 disk creates intermittent clutch slip, producing a vibration felt through the driveline during steady cruising.
- Darkened or burnt transmission fluid – Excessive friction from a failing outer disk generates heat that degrades the ATF, leaving a burnt odor and discolored fluid on the dipstick.
- Intermittent loss of forward or reverse gears – Complete failure of this steel disk can cause the clutch pack to lose clamping force entirely, resulting in temporary neutral conditions under load.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 0501.214.010 |
| Material | Hardened SAE 1050 steel with anti-corrosion coating |
| Outer Diameter | 214 mm (8.43 in) |
| Inner Diameter | 160 mm (6.30 in) |
| Thickness | 2.5 mm (0.098 in) |
| Weight | 0.45 kg (1.0 lb) |
| OEM Reference | ZF 0501.214.010 |
| Surface Finish | Ground, Ra 0.8 µm |
Compatibility
This outer clutch disk is designed for ZF WG series transmissions, specifically the WG158 and WG200 models. It is also compatible with the WG180 series when used in the forward clutch pack (C1). The part fits transmissions found in medium-duty trucks, buses, and off-highway equipment. For proper installation, ensure the HOUS.FRONT SECT is free of scoring, and verify that the OIL TUBE is not obstructed. The disk must be paired with the correct friction discs and the HOUSING REAR PART to maintain proper stack height. Always replace the outer disk in sets with the corresponding inner friction plates to prevent uneven wear.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4656101023 | TRANSMISSION HOUSING | Encloses all rotating components and maintains fluid pressure |
| 4656201016 | HOUS.FRONT SECT | Front section that supports the input shaft and pump |
| 4656301142 | OIL TUBE | Routes hydraulic fluid to clutch packs and valve body |
| 4656201029 | HOUSING REAR PART | Rear section that supports output shaft and PTO mount |
| 0631306816 | CYLINDRICAL PIN | Aligns housing sections during assembly |
| 4656301148 | FIXING PLATE | Secures clutch pack retaining ring in position |
| 0636102489 | CAP SCREW | Fastens housing sections with specified torque |
| 4656301016 | SCREEN SHEET | Fine mesh filter for clutch pack lubrication circuit |
| 4656301017 | SCREEN SHEET | Coarse mesh filter for main sump return line |
| 0636100803 | CAP SCREW | M10 bolt for clutch drum retention |
