Overview
The ZF 0501.327.379 O-RING is a precision-engineered sealing component designed for the WG100, WG130, and WG131 transmission series. This OEM genuine part sits within the hydraulic control circuit and final drive assembly, creating a leak-proof barrier between mating surfaces to maintain consistent oil pressure and lubrication flow. The SKU 0501.327.379 is manufactured from high-grade nitrile rubber (NBR) to withstand extreme temperatures and transmission fluid exposure. When installed alongside a 5838109012: DIFFERENTIAL or 2093209023: DIFFERENTIAL, this O-ring ensures the entire drivetrain assembly remains sealed against contaminants and fluid loss.
Symptoms of Failure
When the ZF 0501.327.379 O-RING deteriorates, operators may notice these specific failure indicators:
- External oil seepage around the differential housing joint – visible drips or wet spots near the mating flange, often mistaken for a housing crack.
- Intermittent gear engagement hesitation – loss of hydraulic pressure causes delayed shifting or slipping under load, especially in WG130 units.
- Low transmission fluid level warnings – gradual fluid loss without obvious external leaks, as the O-ring fails internally between the differential and housing.
- Contaminated fluid with air bubbles – a compromised seal allows air ingress, leading to foamy oil and erratic clutch pack behavior.
Technical Specifications
| Specification | Value |
|---|---|
| Part Number / SKU | 0501.327.379 |
| Material | Nitrile Butadiene Rubber (NBR) – 70 Shore A |
| Inside Diameter | 34.5 mm |
| Cross-Section Thickness | 3.0 mm |
| Weight | 4.2 grams |
| Operating Temperature Range | -40°C to +120°C |
| OEM Reference | ZF 0501.327.379 (Genuine) |
Compatibility
This O-ring is specifically engineered for the ZF WG100, WG130, and WG131 powershift transmission families. It is also compatible with the WG180 and WG200 series when used in the differential-to-housing seal location. The part interfaces directly with the 5838300626: DIFFERENTIAL HOUSING and works in concert with the 0750117075: TAPER ROLLER BEARING to maintain proper axial clearance. Always verify your transmission model suffix before ordering.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 5838109012 | DIFFERENTIAL | Distributes torque to axle shafts |
| 0750117075 | TAPER ROLLER BEARING | Supports differential rotation under load |
| 2093209023 | DIFFERENTIAL | Alternative differential assembly for WG130 |
| 5838300626 | DIFFERENTIAL HOUSING | Encloses differential gears and bearings |
| 0631329088 | SPRING PIN | Secures shift fork alignment |
| 5838300811 | THRUST WASHER | Controls axial play in differential |
| 5838300721 | AXLE BEVEL GEAR | Transfers power to wheel axles |
| 5838300633 | AXLE | Driveshaft connection component |
| 5838300753 | THRUST WASHER | Reduces friction on gear faces |
| 5838300818 | THRUST WASHER | Additional axial load distribution |
Frequently Asked Questions
Q: Can I reuse the ZF 0501.327.379 O-ring after disassembly?
A: No. This is a single-use sealing component. Reusing it risks immediate leakage due to compression set and surface deformation. Always install a new OEM genuine O-ring during any differential or housing service.
Q: How do I know if this O-ring fits my WG131 transmission?
A: Verify your transmission serial number and check the differential housing flange diameter. The 0501.327.379 is the standard seal for all WG100/WG130/WG131 models built after 2005. For earlier units, measure the groove depth to confirm compatibility.
Q: What happens if I install the wrong O-ring size?
A: An undersized O-ring will not seat properly, causing immediate fluid bypass. An oversized ring can bulge and shear during assembly, leading to metal-to-metal contact and eventual housing damage. Always use the exact SKU 0501.327.379 for guaranteed fitment.
