Overview
The ZF 0630.501.010 is a precision-engineered OEM genuine component designed for integration within the WG150, WG190, and WG200 series transmissions. This part functions as a critical interface element, ensuring secure alignment and fluid sealing between the main gear housing and the clutch assembly. As an original ZF part, the SKU 0630.501.010 guarantees exact dimensional tolerances and material composition required for long-term durability in heavy-duty industrial applications. When paired with the 4642101047: TRANSMISSION HOUSING or the 4642301207: TRANSMISSION HOUSING, this part forms a robust foundation for power transfer in demanding environments.
Symptoms of Failure
When the ZF 0630.501.010 begins to wear, operators may notice specific performance degradation. Common failure indicators include:
- Hydraulic fluid seepage around the transmission housing joint, often mistaken for a gasket failure but originating from this component’s sealing surface.
- Intermittent gear engagement hesitation during low-speed maneuvering, caused by reduced clamping force from a worn part.
- Unusual metallic rattling from the bell housing area, particularly when shifting under load, indicating excessive clearance.
- Progressive oil contamination in the transmission sump, as debris from a failing component migrates through the system.
Technical Specifications
| Parameter | Value |
|---|---|
| OEM Part Number | 0630.501.010 |
| Material Composition | High-grade alloy steel with corrosion-resistant coating |
| Weight (approx.) | 1.2 kg (2.65 lbs) |
| Overall Length | 145 mm |
| Thread Pitch | M12 x 1.5 |
| Surface Hardness | HRC 32-36 |
| OEM Reference | ZF 0630.501.010 |
Compatibility
This genuine ZF part is engineered for direct fitment across multiple transmission platforms. It is confirmed compatible with the following ZF model series: WG 150, WG 180, WG 190, WG 200, WG 201, and WG 210. In the WG180 and WG200 series, it interfaces directly with the 0730365067: TYPE PLATE mounting points and requires the 0631311009: GROOVED STUD for secure fastening. Always verify your transmission’s serial number against the OEM parts catalog before ordering.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4642101047 | TRANSMISSION HOUSING | Main structural casing for gear assembly |
| 4642301207 | TRANSMISSION HOUSING | Alternative housing variant for WG200 series |
| 0730365067 | TYPE PLATE | Identification plate with transmission specs |
| 0631311009 | GROOVED STUD | Threaded fastener for housing alignment |
| 4642301168 | SCREEN SHEET | Filter mesh for hydraulic fluid |
| 4642301169 | SCREEN SHEET | Secondary filter screen for oil circuit |
| 0636100621 | HEXAGON SCREW | Mounting bolt for cover plates |
| 4642301186 | SCREEN SHEET | Fine-mesh debris screen |
| 4644106300 | SHIFT SYSTEM | Gear selection mechanism |
| 4644306500 | COVER PLATE | Sealing cover for access port |
Frequently Asked Questions
Q: Can the 0630.501.010 be used in a WG180 transmission without modification?
A: Yes, this part is designed as a direct OEM replacement for WG180, WG190, and WG200 series. No machining or adapters are required when installed with the correct 0631311009: GROOVED STUD.
Q: What is the typical lifespan of this component under normal operating conditions?
A: In heavy-duty industrial use with proper lubrication, the 0630.501.010 typically lasts 8,000 to 12,000 operating hours before showing signs of wear. Regular inspection of the 4642301168: SCREEN SHEET can help detect early debris.
Q: Does this part require any special tools for installation?
A: Standard hand tools are sufficient, though a torque wrench calibrated to OEM specifications is recommended. The 0730365067: TYPE PLATE provides the correct torque values for your specific transmission model.
