Overview
The ZF 0636.104.074 CAP SCREW is a critical fastening component engineered for the WG150 and WG200 transmission series. This OEM genuine part secures the valve body and hydraulic control modules within the transmission housing, ensuring precise clamping force to maintain internal fluid pressure. The SKU 0636.104.074 is specifically designed to withstand high torque loads and thermal cycling, preventing loosening during operation. When paired with the 4642101047: TRANSMISSION HOUSING or the 4642301207: TRANSMISSION HOUSING, this cap screw guarantees a leak-free interface between the housing and cover plates.
Symptoms of Failure
- Transmission fluid seepage from valve body area: A worn or stripped 0636.104.074 cap screw cannot maintain proper sealing torque, leading to slow oil leaks around the housing mating surfaces.
- Erratic gear engagement or delayed shifting: When this fastener loses clamping force, hydraulic pressure drops inside the valve body, causing hesitation between gear changes in WG150/WG200 units.
- Visible thread galling or corrosion on screw head: Exposure to high-temperature transmission fluid degrades the screw’s surface, making removal difficult and risking damage to the 0631311009: GROOVED STUD mounting points.
- Increased vibration noise from transmission casing: A loose cap screw allows micro-movement of internal components, generating audible rattling during acceleration or deceleration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number (SKU) | 0636.104.074 |
| Thread Size | M10 x 1.5 (estimated) |
| Overall Length | 35 mm |
| Head Type | Hexagon socket (Allen) |
| Material | Alloy steel, zinc-plated |
| Weight | 0.04 kg (approx.) |
| OEM Reference | ZF 0636.104.074 |
| Torque Specification | 45 Nm (dry) |
Compatibility
This cap screw is directly compatible with ZF WG150 and WG200 series transmissions, including the WG180 and WG210 variants. It is used in both the main housing assembly and auxiliary cover plate installations. For proper identification, always verify the part against the 0730365067: TYPE PLATE affixed to your transmission, which lists the exact OEM specifications. The screw also interfaces with the 0631311009: GROOVED STUD in certain valve body configurations.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4642101047 | TRANSMISSION HOUSING | Main structural casing for WG150 series |
| 4642301207 | TRANSMISSION HOUSING | Main structural casing for WG200 series |
| 0730365067 | TYPE PLATE | Identification plate with OEM specs |
| 0631311009 | GROOVED STUD | Alignment stud for valve body mounting |
| 4642301168 | SCREEN SHEET | Oil filter screen for WG200 |
| 4642301169 | SCREEN SHEET | Oil filter screen (alternate mesh) |
| 0636100621 | HEXAGON SCREW | Standard fastener for cover plates |
| 4642301186 | SCREEN SHEET | Fine-mesh oil screen |
| 4644106300 | SHIFT SYSTEM | Hydraulic shift control assembly |
| 4644306500 | COVER PLATE | Access cover for valve body |
