Overview
The ZF 0730.003.460 SHIM is a precision-engineered adjustment component designed specifically for the WG150 series transmission. This OEM genuine shim plays a critical role in establishing the correct axial clearance between rotating assemblies and stationary housings within the gear train. By maintaining precise end-play tolerances, the 0730.003.460 ensures optimal load distribution across bearings and gears, directly influencing shift quality and overall drivetrain longevity. As a factory-specification part, it guarantees exact fitment and material integrity for professional rebuilds and maintenance operations.
Symptoms of Failure
- Excessive axial play or gear rattle: When the 0730.003.460 shim wears or compresses beyond tolerance, noticeable end-play develops in the main shaft, producing a distinct rattling noise during deceleration or idle.
- Premature bearing failure: A degraded shim allows improper preload, leading to uneven bearing wear. Technicians often detect this through increased operating noise or metallic debris in the oil pan.
- Oil leaks near the transmission housing interface: Incorrect shim thickness can distort the seal surface between the TRANSMISSION HOUSING and the TRANSMISSION HOUSING, causing fluid seepage under load.
- Intermittent gear slipping under torque: As axial clearance increases, gear engagement depth decreases, resulting in momentary power loss during acceleration or hill climbing.
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | 0730.003.460 |
| Material | Case-hardened steel (C15E) |
| Thickness | 0.50 mm (nominal) |
| Outer Diameter | 62.0 mm |
| Inner Diameter | 38.0 mm |
| Weight | 12 grams |
| OEM Reference | ZF 0730.003.460 |
| Surface Finish | Ground, Ra ≤ 0.8 µm |
Compatibility
This shim is engineered for the ZF WG150 series transmission family. Based on its dimensional profile and application, it is also compatible with the WG180 and WG200 models that share the same planetary carrier and shaft assembly architecture. Always verify the existing shim stack thickness before installation. For complete transmission assembly, ensure the TYPE PLATE is correctly affixed for future identification, and secure all components using the GROOVED STUD at the designated mounting points.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4642101047 | TRANSMISSION HOUSING | Main structural casing for gear assembly |
| 4642301207 | TRANSMISSION HOUSING | Secondary housing section for clutch pack |
| 0730365067 | TYPE PLATE | Identification label for transmission model |
| 0631311009 | GROOVED STUD | Alignment fastener for housing mating |
| 4642301168 | SCREEN SHEET | Oil filtration mesh for valve body |
| 4642301169 | SCREEN SHEET | Fine filtration element for hydraulic circuit |
| 0636100621 | HEXAGON SCREW | Mounting bolt for housing flanges |
| 4642301186 | SCREEN SHEET | Coarse debris screen for oil pump |
| 4644106300 | SHIFT SYSTEM | Hydraulic actuator assembly for gear selection |
| 4644306500 | COVER PLATE | Sealing plate for shift system access |
