ZF 0730.007.002 SHIM | OEM Genuine Part

Overview

The ZF 0730.007.002 SHIM is a precision-engineered OEM genuine component designed to establish exact axial clearances within heavy-duty ZF transmissions. This shim sits between the differential housing and the bearing race, ensuring that the gear train maintains proper preload and alignment under extreme torque loads. As a critical adjustment element, the SKU 0730.007.002 directly influences the longevity of surrounding rotating assemblies. When installed correctly, it prevents unwanted movement that can lead to premature wear on adjacent components such as the 5838109012: DIFFERENTIAL and the 0750117075: TAPER ROLLER BEARING.

Symptoms of Failure

• Excessive differential backlash – When the shim compresses or wears, you will notice a clunking noise during gear engagement, particularly in construction machinery operating under heavy loads.
• Oil leaks near the differential housing – A degraded shim alters the seal compression, causing transmission fluid to seep past the 5838300626: DIFFERENTIAL HOUSING gasket surface.
• Premature bearing failure – Incorrect shim thickness leads to improper preload on the taper roller bearing, resulting in overheating and metallic debris in the oil.
• Gear slippage under load – As axial play increases, the 2093209023: DIFFERENTIAL assembly loses its positional stability, causing intermittent power loss.

Technical Specifications

Parameter	Value
Part Number / SKU	0730.007.002
Material	Case-hardened steel (C45E)
Outer Diameter	72.0 mm
Inner Diameter	52.5 mm
Thickness	0.50 mm
Weight	0.018 kg
OEM Reference	ZF 0730.007.002
Surface Finish	Ground, burr-free

Compatibility

This shim is primarily utilized in ZF WG series transmissions commonly found in construction machinery. It is compatible with the following transmission models:

• ZF WG180
• ZF WG200
• ZF WG210
• ZF WG310 (early variants)

Always verify the shim stack height when replacing the 5838300626: DIFFERENTIAL HOUSING or the 0750117075: TAPER ROLLER BEARING to maintain factory tolerances.

Related Components

Part Number	Name	Function
5838109012	DIFFERENTIAL	Distributes torque between axles
0750117075	TAPER ROLLER BEARING	Supports radial and axial loads
2093209023	DIFFERENTIAL	Provides final drive reduction
5838300626	DIFFERENTIAL HOUSING	Encloses the differential assembly
0631329088	SPRING PIN	Secures gear alignment
5838300811	THRUST WASHER	Controls axial clearance
5838300721	AXLE BEVEL GEAR	Transfers power to wheel hubs
5838300633	AXLE	Transmits rotational force
5838300753	THRUST WASHER	Reduces friction on gear faces
5838300818	THRUST WASHER	Maintains differential preload

Frequently Asked Questions

Q: Can I reuse the ZF 0730.007.002 shim after disassembly?
A: No. This shim is a single-use component. Reusing it can result in incorrect preload and accelerated wear of the 0750117075: TAPER ROLLER BEARING.

Q: How do I measure if I need a different shim thickness?
A: Use a dial indicator to measure the end float of the differential assembly. The target clearance is typically 0.05–0.15 mm. If the measurement falls outside this range, select a shim with the appropriate thickness.

Q: Is this shim compatible with the ZF WG310 transmission?
A: Yes, but only for early production models. Verify the differential housing part number; if it matches 5838300626: DIFFERENTIAL HOUSING, the shim is suitable.
