ZF 0730.102.465 SHIM for WG65 | OEM Genuine Part

Overview

The ZF 0730.102.465 SHIM is a precision-engineered spacer component designed for the WG65, WG150, WG180, WG200, and WG201 series transmissions. This OEM genuine part sits between the transmission housing and the bearing assembly to establish the correct axial clearance and preload within the gear train. By maintaining exact tolerances, the shim ensures that rotating elements align properly under load. The SKU 0730.102.465 is manufactured to ZF’s original specifications, guaranteeing a direct fit without modification. When paired with a TRANSMISSION HOUSING, this shim prevents metal-to-metal contact and extends the service life of internal components.

Symptoms of Failure

• Oil leaks near the bearing bore: A worn or collapsed shim allows the housing to shift, breaking the seal and causing transmission fluid to weep from the joint.
• Gear slipping under load: Incorrect shim thickness reduces bearing preload, leading to axial play that causes gears to disengage during torque application.
• Abnormal whining or grinding noise: Excessive clearance from a degraded shim permits gear teeth to contact unevenly, producing a high-pitched whine that worsens with speed.
• Vibration in neutral or drive: When the shim fails to maintain proper spacing, the entire shaft assembly vibrates, transferring resonance through the driveline.

Technical Specifications

Compatibility

This shim is engineered for the ZF WG65, WG150, WG180, WG200, and WG201 transmission families. It is commonly used in the forward clutch drum and planetary carrier assemblies. Always verify the existing shim thickness before replacement. For proper installation, secure the shim using HEXAGON SCREW fasteners and HEXAGON SCREW bolts. Additional fastening points may require HEXAGON SCREW hardware to achieve the specified torque.
