Overview
The ZF 4642.152.471 CLUTCH is a critical torque-transfer component engineered specifically for the WG 150 Series transmission. This OEM genuine part serves as the primary engagement mechanism, managing power flow between the engine and the gear train. Positioned within the hydraulic control circuit, the clutch assembly ensures smooth gear shifts and reliable load handling under heavy-duty industrial conditions. The SKU 4642.152.471 is manufactured to ZF’s exacting tolerances, guaranteeing a direct fit and long service life. When paired with a robust TRANSMISSION HOUSING (4642101109) or a TRANSMISSION HOUSING (4642301205), this clutch delivers consistent performance in demanding environments.
Symptoms of Failure
When the ZF 4642.152.471 CLUTCH begins to wear, operators often notice specific operational issues. Delayed or harsh gear engagement is a primary symptom, where the transmission hesitates before shifting or clunks into gear. Another common failure sign is slipping under load, where engine RPM rises without a corresponding increase in vehicle speed, particularly during uphill climbs. Oil leaks near the clutch housing may also develop, indicating seal degradation. Finally, intermittent loss of drive in specific gears can occur, often accompanied by burnt transmission fluid odor. Addressing these symptoms promptly prevents damage to adjacent components like the GROOVED STUD (0631311009).
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 4642.152.471 |
| OEM Reference | ZF WG 150 Series |
| Material | High-carbon steel with sintered friction lining |
| Weight | 2.85 kg (6.28 lbs) |
| Outer Diameter | 180 mm |
| Inner Diameter | 120 mm |
| Friction Plate Count | 5 |
| Operating Pressure | 12-15 bar |
| Torque Capacity | 850 Nm |
Compatibility
This ZF 4642.152.471 CLUTCH is primarily designed for the WG 150 transmission series, but it also fits select variants within the ZF WG family. Compatible models include the WG 150, WG 180, and WG 200 transmissions, where the clutch dimensions and spline configuration match. It is also suitable for certain WG 120 and WG 160 units with identical hydraulic circuits. Always verify the TYPE PLATE (0730365125) on your transmission to confirm compatibility before installation. For optimal performance, this clutch works in conjunction with the SHIFT SYSTEM (4644106231) and GASKET (4644306470).
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4642101109 | TRANSMISSION HOUSING | Encloses and protects internal gear assembly |
| 4642301205 | TRANSMISSION HOUSING | Alternate housing variant for WG series |
| 0730365125 | TYPE PLATE | Identifies transmission model and specs |
| 0631311009 | GROOVED STUD | Secures clutch pack alignment |
| 4642301168 | SCREEN SHEET | Filters hydraulic fluid debris |
| 4642301169 | SCREEN SHEET | Secondary filtration element |
| 0636100621 | HEXAGON SCREW | Fastens housing components |
| 4642301186 | SCREEN SHEET | Fine mesh filter for oil circuit |
| 4644106231 | SHIFT SYSTEM | Controls gear selection hydraulics |
| 4644306470 | GASKET | Seals clutch housing against leaks |
