Overview
The ZF 4642.330.189 CONNECTING HOUSING is a critical structural component within the WG150 series transmission assembly. This OEM genuine part serves as the intermediary casing that bridges the main transmission housing to the rear-mounted auxiliary sections, ensuring precise alignment of the drivetrain. Designed to withstand high torsional loads and thermal expansion, the 4642.330.189 connecting housing provides a sealed environment for internal shafts and bearings. When installed correctly, this part maintains the integrity of the entire gear train, preventing misalignment that can lead to premature wear. The SKU 4642.330.189 is machined to exact OEM tolerances for a direct fit, eliminating the need for modifications during rebuilds.
Symptoms of Failure
- Oil seepage at the rear flange joint: A worn or cracked connecting housing often causes transmission fluid to leak between the housing and the TRANSMISSION HOUSING 4642101108, leaving visible drips under the vehicle.
- Abnormal gear engagement noise: When the connecting housing loses its structural rigidity, internal shaft alignment shifts, producing a distinct whining or clunking sound during gear changes.
- Vibration during low-speed operation: A degraded housing can no longer dampen driveline harmonics, resulting in noticeable shaking through the chassis at speeds below 20 mph.
- Recurring seal failures: If the mounting face of the connecting housing becomes warped, new gaskets and O-rings will fail repeatedly, requiring frequent replacement of components like the O-RING 0634303340.
Technical Specifications
| Specification | Detail |
|---|---|
| Part Number | 4642.330.189 |
| Material | High-Grade Aluminum Alloy (A356-T6) |
| Weight | 4.8 kg (10.6 lbs) |
| Overall Length | 245 mm |
| Flange Width | 180 mm |
| Bolt Hole Pattern | 6x M12 on 140 mm PCD |
| OEM Reference | ZF 4642.330.189 |
| Surface Finish | Black Anodized |
Compatibility
This connecting housing is specifically engineered for the ZF WG150 series transmissions, but its mounting pattern also fits select models in the WG180 and WG200 families when used with the correct adapter. The part interfaces directly with the TRANSMISSION HOUSING 4642301208 on the forward side and accepts the GROOVED STUD 0631311009 for secure fastening. For identification purposes, always cross-reference the TYPE PLATE 0730365125 on your unit to confirm the exact series variant before ordering.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4642101108 | TRANSMISSION HOUSING | Main casing that encloses the gear set |
| 4642301208 | TRANSMISSION HOUSING | Intermediate housing for auxiliary sections |
| 0730365125 | TYPE PLATE | Identification tag with serial and model data |
| 0631311009 | GROOVED STUD | Alignment pin for housing positioning |
| 4642301168 | SCREEN SHEET | Fine mesh filter for oil debris |
| 4642301169 | SCREEN SHEET | Coarse mesh pre-filter for fluid intake |
| 0636100621 | HEXAGON SCREW | M12 bolt for housing flange fastening |
| 0630361029 | SEALING CAP | Plugs unused ports to prevent leaks |
| 4642306254 | ADAPTER | Converts housing to alternate bellhousing patterns |
| 0634303340 | O-RING | Seals the connecting housing joint interface |
