Overview
The ZF 4646.102.056 INPUT assembly is a critical OEM sub-assembly engineered for the WG 250, WG 260, and WG 310 series transmissions. This component serves as the primary torque input interface, transferring rotational force from the engine directly into the transmission’s planetary gear set. Designed for heavy-duty industrial applications, the SKU 4646.102.056 ensures precise alignment and load distribution within the driveline. When installed correctly, it minimizes parasitic power loss and maintains the structural integrity of the entire gearbox under high-stress conditions.
Symptoms of Failure
- Oil leaks near the bell housing: A worn input sub-assembly often causes transmission fluid to seep past the sealing surfaces, leading to low fluid levels and overheating.
- Gear slipping under load: If the input splines or bearing surfaces degrade, you may experience intermittent power loss or a “slipping” sensation during acceleration.
- Unusual vibration or whining noise: Excessive play in the input assembly generates a distinct metallic whine or low-frequency vibration, especially at higher RPMs.
- Hard shifting or delayed engagement: A failing input can disrupt hydraulic pressure timing, resulting in rough or delayed gear changes.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 4646.102.056 |
| OEM Reference | ZF 4646.102.056 |
| Material | Case-hardened alloy steel |
| Weight | Approx. 3.2 kg (7.1 lbs) |
| Outer Diameter | 120 mm |
| Overall Length | 185 mm |
| Spline Count | 24 (internal) |
| Sealing Type | Integrated O-ring groove |
Compatibility
This input sub-assembly is specifically designed for ZF WG 250, WG 260, and WG 310 series transmissions. It also fits select variants within the WG 180 and WG 200 families, provided the bell housing and torque converter match the spline configuration. Always verify the pilot bore diameter and bolt pattern before installation. For the WG 261 and WG 311 series, this part is a direct OEM replacement.
During installation, ensure you replace all associated fasteners and seals. Use the 0636115293: 螺栓 and 0736300232: 螺栓 to secure the input housing. The 4475280208: SCREW PLUG seals the hydraulic test port, while the 0634316523: O-RING prevents fluid bypass at the input shaft interface.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 0630361026 | SEALING CAP | Protects the input shaft bore from debris |
| 0501214611 | 齿轮泵 | Provides hydraulic pressure for clutch actuation |
| 0634313945 | O形圈 | Seals the pump-to-housing interface |
| 0501322532 | TEMPERATURE SENSOR | Monitors transmission fluid temperature |
| 0634313366 | O-RING | Seals the sensor port |
| 4646230008 | DIAPHRAGM | Regulates hydraulic pressure modulation |
Authorized ZF Distributor
We are a certified supplier of genuine ZF components.
