Overview
The ZF 4681.301.016 SCREEN SHEET is a critical filtration component engineered for the BP210, BP230, WG190, and WG210 series transmissions. This OEM genuine part, identified by SKU 4681.301.016, sits within the oil sump or valve body assembly, where it captures metallic debris and particulate contaminants before they can circulate through the hydraulic system. By maintaining clean oil flow, this screen sheet protects precision-ground gears, clutch packs, and valve bores from abrasive wear. It is often replaced during a major overhaul alongside the TRANSMISSION HOUSING to ensure the entire oil circuit remains free of obstructions.
Symptoms of Failure
- Erratic shift quality or gear slipping: A clogged screen sheet restricts oil flow to the valve body, causing delayed or harsh engagements. This is a common long-tail search query for “ZF transmission slipping after filter change.”
- Overheating transmission fluid: When the screen sheet becomes perforated or blocked, oil cannot circulate efficiently, leading to elevated sump temperatures and potential thermal damage.
- Visible debris in the oil pan: If the screen sheet tears, large particles bypass the filter, accumulating as sludge or metallic flakes in the pan. This symptom often triggers searches for “ZF BP210 metal shavings in oil.”
- Low line pressure at idle: A restricted screen sheet starves the pump, resulting in insufficient hydraulic pressure that triggers warning lights or limp-home mode.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 4681.301.016 |
| Material | Stainless steel mesh with reinforced frame |
| Mesh Size | 100 microns (estimated) |
| Overall Dimensions | 180 mm x 120 mm x 8 mm |
| Weight | 0.35 kg |
| OEM Reference | ZF 4681.301.016 (genuine) |
| Seal Type | Integrated gasket edge |
Compatibility
This screen sheet is specifically designed for ZF’s BP and WG series powershift transmissions. It is a direct fit for the BP210, BP230, WG190, and WG210 models. It also shares compatibility with the WG180 and WG200 series when used with the correct HOUS.FRONT SECT and HOUSING REAR PART. For applications requiring a different oil routing, verify fitment with the HOUSING REAR SECTION before installation.
Related Components
| Part Number | Name | Function |
|---|---|---|
| 4657101088 | TRANSMISSION HOUSING | Main structural casing for gear and shaft assembly |
| 4657201183 | HOUS.FRONT SECT | Front section housing for pump and clutch |
| 4657201184 | HOUSING REAR PART | Rear housing section supporting output shaft |
| 4657298111 | HOUSING REAR SECTION | Alternate rear housing variant for WG series |
| 0631306816 | CYLINDRICAL PIN | Alignment pin for housing mating surfaces |
| 0636100801 | CAP SCREW | Fastener for screen sheet retention |
| 4681301015 | FIXING PLATE | Secures screen sheet against housing wall |
| 4681301017 | SCREEN SHEET | Alternate mesh variant for different filtration |
| 0636100803 | CAP SCREW | Longer fastener for deeper housing pockets |
| 4681301040 | OIL FEED.HOUSG. | Oil feed channel directing flow to screen |
Frequently Asked Questions
Q: How often should the 4681.301.016 screen sheet be replaced?
A: ZF recommends replacing this screen sheet every 1,000 operating hours or during any major transmission rebuild. If you observe metal debris in the oil, replace it immediately to prevent cascading damage.
Q: Can I clean and reuse this screen sheet?
A: No. The mesh is calibrated to a specific micron rating, and cleaning may distort the openings or leave embedded particles. Always install a new OEM genuine screen sheet to maintain proper filtration.
Q: Will this part fit a WG180 transmission?
A: Yes, the 4681.301.016 is compatible with WG180 models when used with the correct housing sections. Verify that your transmission uses the BP210/BP230 sump configuration or consult the HOUSING REAR SECTION for fitment confirmation.
