ZF 6009.365.800 TYPE PLATE
ZF Part Number: 6009.365.800 (also written as 6009365800 / 6009.365.800 / 6009 365 800)
Compatible ZF Transmission Models
This type plate is used in the following ZF transmission models:
- ZF 4 WG 260
- ZF 5 WG 260
- ZF 6 WG 260
Part Location in Assembly
| Section | Position No. | Qty |
|---|---|---|
| Loose Parts | 010/040 | 1 |
| Loose Parts | 020/040 | 1 |
| Tcu Bp Ec4A | 050 | 1 |
| Tcu Ergopower M L Ec4A | 050 | 1 |
| Tcu Ergopower M L Ec4A | 060 | 1 |
| Wg 210 | 060 | 1 |
Related Parts in Same Assembly
- 0501.006.922 — BRAKE (Qty: 1)
- 0501.214.611 — GEAR PUMP (Qty: 1)
- 0634.304.616 — O-RING (Qty: 1)
- 0634.313.179 — O-RING (Qty: 1)
- 0636.015.124 — HEXAGON SCREW (Qty: 8)
- 0636.015.130 — HEXAGON SCREW (Qty: 6)
- 0730.365.279 — TYPE PLATE (Qty: 1)
- 0750.131.027 — BREATHER (Qty: 1)
Frequently Asked Questions
What is ZF part number 6009.365.800?
ZF 6009.365.800 is an OEM type plate produced by ZF Friedrichshafen AG, one of the world’s largest automotive suppliers. It is designed for use in ZF powershift transmissions, specifically in models such as 4 WG 260, 5 WG 260, 6 WG 260. This is a genuine ZF component, not an aftermarket reproduction.
Which ZF transmissions use 6009.365.800?
This type plate is found in 3 ZF transmission variants, including: 4 WG 260, 5 WG 260, 6 WG 260. These transmissions are commonly used in wheel loaders, graders, and other heavy construction equipment. Contact us to verify fitment for your specific machine.
Where is ZF 6009.365.800 installed in the transmission?
This type plate is located in the loose parts, tcu ergopower m l ec4a area of the transmission. It appears in 30 different assembly configurations. In the service manual, look for position number 010/040 in the Loose Parts section.
How do I look up ZF part 6009.365.800?
This part can be found under several formats: 6009365800 / 6009.365.800 / 6009 365 800. All formats refer to the same genuine ZF component. When ordering, any of these numbers will work. The official ZF catalog uses the dotted format (6009.365.800).
Where can I buy ZF 6009.365.800?
You can purchase genuine ZF 6009.365.800 from PartsZF.com (operated by Tianjin Xiaohang Construction Machinery Co., Ltd). We maintain direct supply channels with ZF and offer worldwide shipping. Contact our parts specialists for current pricing and lead times.
Need this part? Contact our ZF parts specialist for pricing and availability. We ship worldwide with OEM quality guarantee.
Exploded View / Assembly Diagram
The diagram below shows where ZF 6009.365.800 is located within the transmission assembly.
