Overview
This genuine ZF 0636.302.067 screw plug serves as a critical sealing component within the hydraulic circuit of heavy-duty construction machinery transmissions. Specifically engineered for the WG100, WG130, and WG131 series, this OEM part ensures a leak-proof seal at designated oil drain or fill ports on the transmission housing. The SKU 0636.302.067 is precision-machined to maintain consistent clamping force, preventing contaminants from entering the gearbox while retaining essential lubricant under high-pressure operating conditions. Its robust construction directly supports the longevity of internal planetary gears and clutch packs by maintaining proper fluid levels.
Symptoms of Failure
When the ZF 0636.302.067 screw plug degrades or becomes damaged, operators may encounter several distinct operational issues:
- Transmission oil seepage at drain port – A slow, persistent drip from the plug area often indicates thread wear or a compromised sealing face, leading to gradual fluid loss.
- Contaminated hydraulic fluid – A loose or cracked plug allows dirt, water, and debris to bypass the seal, resulting in gritty or milky oil that accelerates internal wear.
- Inconsistent gear engagement under load – Low fluid levels caused by a failing plug can lead to erratic shifting or delayed clutch pack actuation during heavy excavation work.
- Visible corrosion or thread stripping – Repeated thermal cycling may cause the plug’s threads to gall or corrode, making removal difficult and compromising the seal integrity.
Technical Specifications
| Parameter | Value |
|---|---|
| OEM Part Number | 0636.302.067 |
| Thread Size | M22 x 1.5 (estimated) |
| Overall Length | 28 mm |
| Head Diameter | 30 mm (hexagonal) |
| Material | Steel, zinc-plated |
| Sealing Type | Integrated copper washer (replaceable) |
| Weight | 0.08 kg |
| Torque Specification | 45 Nm (recommended) |
Compatibility
This genuine screw plug is specifically designed for the following ZF transmission models used in construction machinery:
- ZF WG100 – Common in wheel loaders and telehandlers requiring moderate torque capacity.
- ZF WG130 – Found in medium-duty graders and compact excavators with higher hydraulic flow demands.
- ZF WG131 – Used in heavy articulated dump trucks and large loaders where sealing integrity is critical.
- ZF WG180 – Compatible for oil drain applications in certain high-torque variants (verify thread pitch).
- ZF WG200 – Suitable for auxiliary port sealing in extreme-duty mining equipment.
Always cross-reference your transmission serial number with the 0636.302.067 part to confirm fitment, as thread variations exist across production years.
